Frame
Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5 mm QR
-
Fork
FX steel, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR
-
Hub front
Formula DC-20, alloy, 6-bolt, 100x5 mm
-
Skewer front
139x5 mm bolt-on
-
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm
-
Skewer rear
152x5 mm QR
-
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
-
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
-
Shifter
Size: S, M, L, XL
Shimano EF500, 8-speed
Size: S, M, L, XL
Shimano EF500, 2-speed
-
Front derailleur
Shimano Tourney TY606, 31.8/34.9 mm clamp, top swing, dual pull
-
Rear derailleur
Shimano Acera M3020-8, 40T max cog
-
Crank
Forged alloy, 46/30, 170 mm length
-
Bottom bracket
Sealed cartridge, 68 mm
-
Cassette
Shimano 8-speed, 12-32T
-
Chain
KMC Z8.3
-
Pedal
Wellgo nylon platform
-
Saddle
Bontrager Sport Women's
-
Seatpost
Size: S, M
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Size: L, XL
Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length
-
Handlebar
Bontrager Riser, steel, 25.4 mm, 30 mm rise, 600 mm width
-
Grips
Trek Line Ergonomic Comp, lock-on
-
Stem
Size: S, M
Bontrager alloy, 25.4 mm clamp, 10-degree, 90 mm length
Size: L, XL
Bontrager alloy, 25.4 mm clamp, 10-degree, 110 mm length
-
Brake
Tektro MD-U310 mechanical disc
-
Brake rotor
Tektro wave, 6-bolt, 160 mm
-
Weight
M - 12.85 kg / 28.33 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
