Frame
OCLV Mountain Carbon, removable battery, high main pivot, idler pulley, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, magnesium rocker link, upper chain guide mount, 55 mm chainline, ABP, UDH, 148x12 mm thru axle, 170 mm travel
Fork
RockShox ZEB Ultimate, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, Maxle Stealth, 170 mm travel
Shock
RockShox Vivid Ultimate, 230 mm x 65 mm
Max Compatible Fork Travel
190 mm
Wheel Front
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Wheel Rear
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru-axle, 27.5"
Skewer Rear
Bontrager Switch thru-axle, removable lever
Tyre Size M, L, XL
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 27.5 x 2.50"
Tyre Size M, L, XL
Bontrager SE6 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50", Fork: See manufacturer
Battery Size M, L, XL
TQ 580Wh
Battery Size M, L, XL
SRAM eTap battery pack (with charger)
Charger
TQ 4A charger
Rear Derailleur
SRAM X0 Eagle AXS, T-Type
Crank
SRAM X0 Eagle, 160 mm length
Cassette
SRAM Eagle XS-1295, T-Type, 10-52, 12-speed
Chain
SRAM X0 Eagle, T-Type, 12-speed
Max. Chainring Size
1x: 34T, min 30T
Saddle
Verse Short Comp, steel rails, 145 mm width
Seatpost
RockShox Reverb AXS, 170 mm travel, wireless, 34.9 mm, 480 mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Grips
Bontrager XR Trail Elite, nylon lock-on
Stem
Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 35 mm length
Brake
SRAM Maven Silver 4-piston hydraulic disc
Brake Rotor
SRAM 6-bolt, 200 mm
Rotor Size
Max brake rotor sizes – Frame: 220 mm, min 200 mm, Fork: see fork manufacturer
Tool
Bontrager BITS integrated multi-tool
Weight
M - 20.88 kg / 46.04 lbs (with TLR sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
