Frame
Alpha Smooth Aluminium, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Fork
SR Suntour XCR32, coil spring, preload adjuster, lockout,100 mm QR, 60mm travel
Max compatible fork travel
50 mm
Hub front
Formula CL-51 alloy, 100x5 mm QR
Skewer front
100 mm bolt-on
Hub rear
Formula CL-52 alloy, 135x5 mm QR
Rim
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tyre
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"
Max tyre size
27.5x2.40" with or without mudguards
Charger
Bosch standard 4A, 230V, smart system
*Computer
Size: XS, S, M, L, XL
Bosch Kiox 300, smart system
Size: XS, S, M, L, XL
Bosch LED remote, smart system
Motor
Bosch Performance Line Cruise, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Shifter
Shimano Altus M2010, 9-speed
Rear derailleur
Shimano Altus M2000, long cage
*Crank
Size: XS, S, M
ProWheel alloy, 170 mm
Size: L, XL
ProWheel alloy, 175 mm length
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
Cassette
Shimano HG200, 11-36, 9-speed
Chain
KMC E9S, 9-speed
Pedal
VP-536 nylon platform
Saddle
Selle Royal Vivo Moderate Ergo
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Bontrager aluminium touring
Grips
Bontrager XR Trail Comp, nylon lock-on
*Stem
Size: XS
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: S
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size: L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size: XL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
*Brake rotor
Size: XS, S, M, L, XL
Shimano RT30, CentreLock, 180 mm
Size: XS, S, M, L, XL
Shimano EM300, CentreLock, 180 mm
Brake Set
Tektro HD-M275 hydraulic disc
*Light
Size: XS, S, M, L, XL
Spanninga SOLO for e-bike
Size: XS, S, M, L, XL
Herrmans MR4, 120-lumen LED
Kickstand
Pletscher Comp Flex 18
Cargo rack
MIK-compatible alloy rear rack, maximum load 25 kg
*Mudguard
Size: XS, S, M, L, XL
SKS plastic, rear
Size: XS, S, M, L, XL
SKS plastic, front
Weight
M – 26.50 kg (with 545 Wh battery)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
