Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork
SR Suntour XCM 34, air spring, lockout, rebound adjuster, tapered steerer, Boost110, 15mm thru axle, 120mm travel
Hub front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.40" (Size S), 29x2.40" (Size M, L, XL)
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 2A, 230V, smart system
E-bike classification
Class 1
Shifter
Shimano U6000, 10-speed
Rear derailleur
Shimano CUES U6000 GS
Crank
FSA Bosch CK-220, 36T ring, 165 mm length
Chainring
FSA, 36T, steel
Cassette
Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain
Shimano LG500, 9/10/11-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 42T
Saddle
Bontrager Commuter Comp
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm (S), 360 mm (M), 400 mm (L, XL)
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake rotor
Tektro, CentreLock, 203 mm
Max brake rotor size
Frame: 203mm
Weight
24.90 kg (Size M)
Weight limit
136 kg (combined weight of bicycle, rider and cargo)
