Frame
800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
-
Fork
Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100 mm thru axle
-
Weight
56 – 12.85 kg/28.33 lb (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
-
Battery
TQ 360Wh
-
Charger
TQ 4A charger
-
Computer
TQ LED display with Bluetooth & ANT+ connectivity
-
Motor
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
-
Front derailleur
Shimano 105 R7150 Di2, braze-on, down swing
-
Rear derailleur
Shimano 105 R7150 Di2, 36T max cog
-
Crank
Size: 50, 52: Praxis Carbon, 165mm length; Size: 54, 56: Praxis Carbon, 170 mm length; Size: 58, 60, 62: Praxis Carbon, 172.5 mm length
-
Chainring
Praxis, 50/34T, 12-speed
-
Cassette
Shimano 105 7101, 11-34, 12-speed
-
Chain
Shimano SLX M7100, 12-speed
-
Max. chainring size
1x: 46T, 2x: 52/36
-
Wheel front
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
-
Wheel rear
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11/12-speed freehub, 142x12 mm thru axle
-
Tyre
Bontrager Kwaremont Pro TLR, tubeless ready, folding bead, Race Dual-Compound, 120 tpi, 700x32 mm
-
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
-
Max tyre size
40 mm without mudguards, 35 mm with mudguards
-
Saddle
Verse Short Comp, steel rails, 145 mm width
-
Seatpost
Size: 50, 52, 54, 56: KVF aero carbon seat post, 20 mm offset, 280 mm length; Size: 58, 60, 62: KVF aero carbon seat post, 20 mm offset, 320 mm length
-
Handlebar
Size: 50, 52: Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width; Size: 54, 56: Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width; Size: 58, 60, 62: Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
-
Handlebar tape
Bontrager Supertack Perf tape
-
Stem
Size: 50: Trek RCS Pro, -7-degree, 80 mm length; Size: 52, 54: Trek RCS Pro, -7-degree, 90 mm length; Size: 56, 58: Trek RCS Pro, -7-degree, 100 mm length; Size: 60, 62: Trek RCS Pro, -7-degree, 110 mm length
-
Brake rotor
Shimano RT70, CentreLock, 160 mm
-
Rotor size
Max brake rotor sizes: 180 mm front, 160 mm rear
